127
1)After remove the panel
plate following procedure 1
2)
Remove
the nut fixing
the fan,and remove the
fan.
3)
Unf
ix the hooks and
then open the electronic
control box cover.
○
2
○
3
Compressor and liquid-gas separator
reactor
