Instr 9929139 Rev 01 2018-08 Page 2 of 13
REF
QTY PART DESCRIPTION
PART NUMBER
9 1 Winch Cable 2878889
10 1 Battery Cable, Positive 4018231
11 1 Battery Cable, Negative 4018231
12 1 Winch control Harness 2414804
13 6 Screw - CAR, M10 X 1.5 X 25 7519372
14 4
Screw - M12 X 1.75 X 25 7519072
15 4
Screw - HXFL, M8 X 1.25 X 20 7519133
16 2 Nut, Battery Cable 7547270
17 4 Locking Nut - M12 X 1.75 7547441
18 6 Locking Nut - M10 x 1.5 7547423
1 Instructions 9929139
TOOLS REQUIRED
• Safety Glasses
• Drill
• Drill Bit: 1/4” (6mm)
• Pliers, Push Pin Rivet
• Pliers, Side Cutting
• Socket Set, Hex Bit, Metric
• Socket Set, Metric
• Socket Set, Torx
®
Bit
• Torque Wrench
• Wrench Set, Metric
IMPORTANT
Your Polaris
®
4500 HD Winch Kit is exclusively designed for your vehicle. Please read the installation
instructions thoroughly before beginning. Installation is easier if the vehicle is clean and free of debris. For your
safety, and to ensure a satisfactory installation, perform all installation steps correctly in the sequence shown.
ASSEMBLY TIME
Approximately 48 minutes
NOTE
Additional time may be required for optional steps, or
to accommodate other installed accessories.
