Polaris GAS WATER HEATER User Manual

IS PRESSURE SWITCH
OPEN
TURN ON BLOWER
CONTROL POWER
UP
TURN OFF BLOWER, AND TURN
ON IGNITER FOR 35 SECOND
WARM-UP
IS PRESSURE SWITCH OPEN
IGNORE PRESSURE SWITCH
FOR 5 SECONDS
TURN OFF IGNITER FOR 1 SECOND
FLAME PROVING PERIOD
IS FLAME PRESENT
TURN ON BLOWER AND
GAS VALVE FOR 3 SECONDS
WAS THIS THE 3RD ATTEMPT
LOCKOUT
STEADY STATE HEATING
YES
YES
NO
NO
NO
NO
YES
NO
TURN OFF BLOWER FOR 60 SECONDS
TURN OFF GAS VALVE
YES
IS THE PRESSURE
SWITCH CLOSED WITHIN
60 SECONDS
NO
IS PRESSURE SWITCH
CLOSED
6 SECOND PRE-PURGE
1018-525 SOFTWARE OPERATION SEQUENCE
28
NO
WAS THIS THE 3RD
FLAME LOSS
IS PRESSURE SWITCH
CLOSED
IS FLAME
PRESENT AND PRESSURE
SWITCH CLOSED
30 SECOND
INTER-PURGE
YES
NO
NO FLAME
PRESSURE SWITCH
OPEN
YES
YES
YES
YES
NO
