ALTERNATOR
BLK
CHARGING SYSTEM -- LEGEND
RED 12V BATTERY VOLTAGE
BLACK CHASSIS GROUND
RED/PUR FUSE P ROTECTED / SWITCHED BATTERY VOLTAGE
YEL/RED STARTER RELAY SIGNAL
PURPLE SWITCHED ECU VOLTAGE
D
D
D
VOLTAGE
REGULATOR
D
D
D
A
B
A B C D E F
30A
SPARE SPARE
RED/YEL
RED
STARTER RELAY
A
B
RED
ELECTRICAL SYSTEMS
8.92004 Four Stroke PWC Service Manual
Charging System
