ELECTRICAL

7.8

COMPONENTS OF ES50PL ALTERNATOR

DC/CDI

IGNITION

Refer to Page 7.7 for

Flywheel identification.

Resistor

Cap

CDI Box

Stator

Pulse Coil (Trigger)

Air Gap: .016-.030s

(.4-.75mm)

Meter

Ignition Coil

.3 :

Ignition Kill

Wire

(Black)

Coil Lead

Refer To Wiring Diagrams For

Specified Stator Coil Resistance

Starter

Solenoid

Meter

190:

Note: DC /CD I compone nts ar e not compa tible with any other type of ignition

12 Volt DC

Supply Wire

(Red)

11.3k:

Meter

One way starter clutch

Starter Drive gear

Reverse Signal Coil

(Located in stator)

.5 -- .1

Primary Coil
