83
MAINTENANCE AND LUBRICATION
Lights
Taillight /Brakelight Lamp Rep lacement
If the taillight/brakelight does not work the lamp may need to be
replaced.
1. Remove the t aillight lens cover
mounting screws. Remove the
lens cover and gasket and set
aside for reassembly.
2. Remove the lamp (1).
3. Apply dielectric grease to t he
socket and install the new
lamp.
4. Test the taillight/brakelight to
see that it’s working.
5. Reinstall the gasket and lens cover.
Indicator Lamp Replacemen t
1. Remove the instrument panel or front cover, if necessary, to access
the back of the indicator panel.
2. Using a small, straight-blade screwdriver, turn the base of t he bulb
1/4 turn counterclockwise.
3. Using a needle-nose plier or similar tool, pull t he lamp out of the
indicator panel housing.
4. Insert the new bulb and seat it by turning i t 1/4 turn clockwise.
5. Reinstall the instrument panel or front cover.
1
