91
MAINTENANCE AND LUBRICATION
Battery
WARNING
Improperly connecting or disconnecting battery cables can result
in an explosion and cause serious injury or death. When
removing the battery, always disconnect the negative (black)
cable first. When reinstalling the battery, always connect the
negative (black) cable last.
Battery Removal
1. Disconnect the hold-down strap holding the battery in position, and
remove battery cover.
2. On conventional batteries, remove the battery vent tube.
3. Disconnect the black (negative) battery cable first.
4. Disconnect the red (positive) battery cable next.
5. Lift the battery out of the ATV. Be careful not to tip a conventional
battery sideways, which could spill electrolyte.
CAUTION
If electrolyte spills, immediately wash it off with a solution of one
tablespoon baking soda and one cup water to prevent damage to
the vehicle.
