28 Legend
VIII. COMFORT ADJUSTMENTS
TILLER ANGLE ADJUSTMENT
Your scooter is equipped with a pivoting tiller that
allows adjustment to several positions from the scooter
deck to the furthest forward stop.
1. Lift the tiller adjustment lever. See figure 9.
2. Move the tiller to a comfortable position.
3. Release the tiller adjustment lever to secure the
tiller in position.
SEAT LOCK
LEVER
SEAT SLIDING LEVER
FIGURE 10. SEAT ADJUSTMENTS
SEAT ROTATION
The seat lock lever will lock the seat into several
positions.
1. Push forward on the seat lock lever to unlock the
seat. See figure 10.
2. Rotate the seat to the desired position.
3. Pull back firmly on the the seat lock lever to lock
the seat securely in place.
FRONT-TO-BACK SEAT ADJUSTMENT
You can reposition the Legends seat forward or
rearward to adjust the distance between the seat
and the tiller. See figure 10.
1. Move the seat sliding lever outward.
2. While holding the lever out, slide the seat forward
or rearward.
3. Release the seat sliding lever once the seat is in the
desired position.
FIGURE 9. TILLER ADJUSTMENT
TILLER ADJUSTMENT
LEVER
WARNING! Remove the key from the key switch before adjusting the tiller or the seat. Never
attempt to adjust the tiller or the seat while the scooter is in motion.
