Transporting the Post Driver.
To put the Post driver into transport position, operate the slew control to
position the slew arm parallel with the main frame (slew cylinder closed). If the
rock spike option is fitted ensure the diverter lever is pulled towards to operate
the slew function.
Fit the slew lock pin and mast forward tilt and mast side tilt safety lock plates.
Always ensure the telescopic is fully retracted and the mast tilt ram is fully
closed.
Always transport the post driver with the weight fully lower and with the front
legs fully raised so the machine is carried as low as possible on the tractor
linkage without causing obstruction
Always ensure the rock spike (if fitted) is retained with the rock spike lock pin
in the rock spike carrier.
Safe use of the Post Driver.
1.
Manually start a post in the desired location so it becomes self supported.
Under no circumstances should the post be held manually while operating the
Post Driver. The Post driver controls are positioned to keep the operator at a
safe distance and provide good visibility of the work area. Under no
circumstances should the control panel position be moved, and the operator
must stay within a safe working zone
2.
With the tractor and machine near to the work area remove to slew lock pin
and safety lock plates.
Store the lock plates as shown below:-
