mA Output (LOOP) Menu
P834 mA Low Level
This parameter sets, in Measurement Units (P104), the value of ‘level’,
‘distance’ or ‘space’, depending on the selected Mode of Operation (P100),
at which 4mA will occur.
P835 mA High Level
This parameter sets, in Measurement Units (P104), the value of ‘level’,
‘distance’ or ‘space’, depending on the selected Mode of Operation
(P100), at which 20 mA output will occur.
P838 mA Low Trim
If the device you are connected to is not calibrated, and not showing the low
value, then you can trim it using this parameter. You can either type in the
offset directly, or use the arrow keys to move the output up and down until
you get the expected result on the device that is connected.
P839 mA High Trim
If the device you are connected to is not calibrated, and not showing the
high value, then you can trim it using this parameter. You can either type in
the offset directly, or use the arrow keys to move the output up and down
until you get the expected result on the device that is connected.
P840 mA Fail-safe Mode
This parameter determines what happens to the mA output in the event of
the unit going into fail-safe mode. The default is to do the same as the
system fail-safe (P808), but this can be overridden to force the mA output
to an independent fail-safe mode as follows:
Option Description
0 = Default mA output will fail as per P808.
1 = Hold mA output will retain its last known value.
2 = Low mA output will fail to its low condition. 3.5mA
3 = High mA output will fail to its high condition. 22mA
