Page 36
P842 Voltage Output
This parameter will determine the range of the voltage output. The voltage
output will automatically be scaled to represent the Span P106 where
0volts represents 0% (empty) and maximum voltage 5 or 10 volts,
depending on range selected, will represent 100% (full).
Option Description
0 = 5 volts Voltage output range will be 0 - 5volts.
1 = 10 volts Voltage output range will be 0 - 10volts.
Additional Information
In the event of a failsafe condition occurring, the voltage output will fail
in accordance with the Failsafe Mode P808
Compensation (CoP) Menu
P851 Measurement Offset
The value of this parameter is added to the measured distance, in
Measurement Units (P104).
This Offset will be added to the level, as derieved from the transducer, and
will affect everything including the reading on the display, the relay
setpoints and the mA output.
P852 Temperature Source
Default = 1
This parameter determines the source of the temperature measurement. By
default it is set to internal (transducer) (P852=1), which will automatically
detect the temperature from the transducer. If for any reason, no temperature
input is received, then the Fixed Temp value is used, as set by P854.
The temperature source can be specifically set as follows:
Option Description
1 = Internal (Default)
Always uses temperature reading from
transducer.
3 = Fixed Always uses fixed temperature (P854)
