13
Technical Parameters
Item Parameter
Engine
Engine Model 148F/P -2 164F/P
Engine Type
Bore size × Stroke (mm) 48.6×43
Displacement (cc) 79.7 145
Compression Ratio 8.7± 0.2 8.7± 0.2
Cylinder Head OHV OHV
Cooling Mode Forced Air Forced Air
Output Power (kW/r/min) 2.1/4500 3.8/4650
Starting Method Recoil
Fuel Tank Volume (L)
Fuel Type and Grade
Lubricating Oil Capacity
Lubricating Oil Model
Lubrication Mode Splash Lubrication Splash Lubrication
Noise dB (at 7m) 62 63
Generator
Rated Power (kW) 1.8 2.8
Rated Voltage (V) 120 120
Rated Frequency (Hz) 60 60
Rated Power Factor 1 1
Phase Number Single Phase Single Phase
Configuration
Motor Brushless (Permanent Magnet)
Voltage Regulation Inverter Regulation
Frequency Regulation Inverter regulation
Overall Dimension (mm) 18.9”x11.5”x17” 18.9”x11.5”x17”
Net Weight
Single-cylinder, four-stroke, air-cooled, overhead valve,
tilted 25º of the center of gasoline engine cylinder
64×45
1.1 Gallon (4L)
1 Gallon (3.7L)
Gasoline or Propane
12 Ounces (0.35L) 15 Ounces (0.45L)
SAE 10w-30
SAE 10w-30
40lbs. (18kg) 46lbs. (21kg)
