LED Indicators Instructions
Condition RUN ALR 1 2 3 4 5 6
Power off - - - - - - - -
Power on ŏ ŏ ŏ ŏ ŏ ŏ ŏ ŏ
Idle/Normal ŏ - - - - - - -
Charge ŏ -
Show soc; highest LED flash
on: 0.5s; off 0.5s
Discharge ŏ Show soc
Alarm ALR:ŏ; Other LEDs are same as above.
System
error/Protect
- ŏ - - -
- -
ŏ/ŏ ON
ŏ flash, on: 0.3s; off: 3.7s
ŏ/ŏ flash, on:0.5s; off: 1.5s
BMS function:
Protection and Alarm Management and Monitor
Charge/Discharge End Cells Balance
Charge Over Voltage Intelligent Charge Model
Discharge Under Voltage Charge/Discharge Current Limit
Charge/Discharge Over Current Capacity Retention Calculate
High/Low Temperature(cell/BMS) Administrator Monitor
Short Circuit Operation Record
Power Cable Reverse
