WARNINGS
•
This installation has to be grounded. An improper grounding can cause electrical shocks. Do
not use extension cords. This can cause fire or electrical shocks.
• The building installation has to be equipped with an earth-leakage circuit breaker. If this is not
the case electrical shocks and fire can occur.
Attach the condensed water drainage according the installation instruction.
• In case of faulty drains/piping water can leak out of the unit which can lead to wet and
damaged household goods.
2. PARTS SUPPLIED:
2.1 Parts supplied for the SC 39xx models
Number Indication of accessories Quantity
1 Installation plate 1
2 Plugs 6
3 Self-tapping screw ‘A’ 6
4 Drain connection 1
5 Connection pipe 1
6 Remote control 1
7 Self-tapping screw ‘B’ 2
8 Remote control holder 1
2.2 Parts supplied for the S 39xx models.
No. Indication of accessories Quantity
1 Installation plate 1
2 Plugs 6
3 Self-tapping screw ‘A’ ST 3.9 x 25 6
4 Drain connection 1
5
Connection pipe
Fluid side
Ø 6.35 (< 6.5 kW version)
Ø 9.53 (> 6.5 kW version)
Not included
Gas side
Ø 9.53 (< 3.5 kW version)
Ø 12.7 (≥ 3.5 kW version)
Ø 16.0 (≥ 6.5 kW version)
6 Remote control 1
7 Self-tapping screw ‘B’ 2
8 Remote control holder 1
G
ATTENTION!
Besides the parts mentioned above, other parts necessary during the installation have to be
purchased by the buyer of the air conditioning.
