QNAP TS-128A User Manual

c. Attach the tool-less screw to the bottom of the NAS.
8. Connect all cables and external attachments.
9. Connect the power cord to the electrical outlet.
10. Power on the NAS.
QTS Installation
Installing QTS Using Qfinder Pro
Warning
Installing QTS deletes all data on the drives. Back up your data before proceeding.
1. Power on the NAS.
2. Connect the NAS to your local area network.
3. Run Qfinder Pro on a computer that is connected to the same local area network.
Note
To download Qfinder Pro, go to https://www.qnap.com/utilities.
4. Locate the NAS in the list and then double-click the name or IP address.
The Smart Installation Guide opens in the default web browser.
5. Perform any of the following actions.
• To check for the latest available version, click Start.
The wizard downloads the latest available version, and then the NAS restarts after the download
is complete. If a newer version is not available, the wizard automatically displays the Smart
Installation Guide.
• To install the out-of-the-box version, click Skip.
6. Click Start Smart Installation Guide.
TS-x28A User Guide
Installation and Configuration 10

QNAP TS-128A Specifications

General

Bad block scan	Yes
Storage drive size	- \
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4
Storage drive interface	-
Storage drives installed	No
Storage drive sizes supported	3.5 \
Supported storage drive types	HDD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	1
Supported storage drive interfaces	Serial ATA, Serial ATA II, Serial ATA III
Processor cores	4
Processor family	Realtek
Processor frequency	1.4 GHz
Processor architecture	ARM Cortex-A53
Flash memory	4000 MB
Internal memory	1 GB
Internal memory type	DDR4
Ethernet LAN data rates	1000 Mbit/s
USB 2.0 ports quantity	2
Chassis type	Mini Tower
Cooling type	Active
Fan diameter	40 mm
Product color	White
LED indicators	Network, Status, System
Number of fans	1 fan(s)
Type	NAS
Device class	Home & Home Office
Backup features	Cloud, iSCSI LUN
Browser supported	Apple Safari 7, Google Chrome, Microsoft Internet Explorer 10, Mozilla Firefox
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH
Operating system version	4.3.4
Operating system installed	QNAP Turbo System
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply location	External
Power consumption (typical)	7.06 W
Power consumption (HDD standby)	2.9 W
Power supply unit (PSU) capacity	36 W
Cables included	AC, LAN (RJ-45)
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	125 mm
Width	60 mm
Height	187.7 mm
Weight	560 g
Package weight	1740 g
