8 / 16
3.2 Specifications2018
CPU
Processor RK-3368H, ARM Octa-core Cortex-A53, Quad Core CPU,
1.5GHz
Memory
RAM 2GB LPDDR3
Flash 16GB EMMC Flash
Display
LCD 7" TFT LCD
Resolution 1024*600 24bit Color
Display Colors 16.7M
Brightness 250cd/m2
View Angle 80U/80D, 80L/80R
Touch Screen Cap-touch, multi-point
Supported
format
Audio MP3, 3GPP, WAV
Video MP4, 3GPP
Picture BMP, GIF, JPEG, PNG
Interfaces
USB 1X Micro USB2.0 OTG
Wireless 1xwifi 802.11b/g/n/ac, 1xBluetooth4.2, with inner FPC
antenna
Internal Audio Internal Speaker
Internal MIC
RTC Supported
Gas gauge Supported
Camera 1x5M Front Camera (Fixed Focus)
Software OS Android 7.1
Power
Battery 3.7V, 2400mAh
DC Power Supply 7V, 1A
Mechanical
Dimensions 191x116.7x19.7mm
Weight 0.45Kg
Environment
Condition
Temperature
Operating Temperature: 0℃ ~ +40℃
Storage: -20℃ ~ +45℃, Recommended:26±5℃
Humidity 10-85%RH (Non-Condensation), operating and storage
Vibration 2G, 9-26Hz (10 times in X, Y, Z directions)
