Quantum Scalar i500: Rackmount Kit Installation
6-01492-04 Rev A
December 2013
4 Preparing for Installation
Table 2 Rack Ear Kit Contents
Rack shelf, left —
Secures the modules
in the rack
1
Rack shelf, right—
Secures the modules
in the rack
1
Component Description Quantity
Component Description Quantity
Nut clip — Used in
racks with square
holes
4
Cage nut — Used in
racks with round
holes
4
M5 thumbscrew —
Secures the rack ears
4
