GSM/GPRS/NB-IoT Module Series
BC68&M66 Compatible Design
BC68&M66_Compatible_Design 23 / 31
5 Recommended Footprint and Stencil
Design
This chapter mainly introduces the recommended footprint and stencil design for BC68 and M66
modules.
5.1. Recommended Compatible Footprint
The following figure shows the bottom view of BC68 and M66.
BC68 M66
Figure 15: Bottom View of BC68/M66
