EC200U_Series_Hardware_Design 70 / 94
Table 42: Operating and Storage Temperatures
Parameter
Min.
Typ.
Max.
Unit
Operating Temperature Range
10
-35
+25
+75
ºC
Extended Temperature Range
11
-40
+85
ºC
Storage Temperature Range
-40
+90
ºC
5.4. Power Consumption
Table 43: EC200U-CN Current Consumption
Description
Conditions
Typ.
Unit
OFF state
Power down
31
μA
Sleep state
AT+CFUN=0 (USB disconnected)
1.126
mA
EGSM900 @ DRX = 2 (USB disconnected)
3.271
mA
EGSM900 @ DRX = 5 (USB disconnected)
2.637
mA
EGSM900 @ DRX = 5 (USB suspend)
4.105
mA
EGSM900 @ DRX = 9 (USB disconnected)
2.448
mA
DCS1800 @ DRX = 2 (USB disconnected)
3.265
mA
DCS1800 @ DRX = 5 (USB disconnected)
2.637
mA
DCS1800 @ DRX = 5 (USB suspend)
4.206
mA
DCS1800 @ DRX = 9 (USB disconnected)
2.457
mA
LTE-FDD @ PF = 32 (USB disconnected)
2.515
mA
LTE-FDD @ PF = 64 (USB disconnected)
1.832
mA
10
Within the operating temperature range, the module meets 3GPP specifications.
11
Within the extended temperature range, the module remains the ability to establish and maintain functions such as voice,
SMS, data transmission, etc., without any unrecoverable malfunction. Radio spectrum and radio network are not influenced,
while one or more specifications, such as Pout, may exceed the specified tolerances of 3GPP. When the temperature
returns to the operating temperature range, the module meets 3GPP specifications again.
