1. “*”means under development.
2.
1)
Within operating temperature range, the module is 3GPP compliant.
3.
2)
Within extended temperature range, the module remains the ability to establish and maintain a
voice, SMS, data transmission, emergency call, etc. There is no unrecoverable malfunction; there are
also no effects on radio spectrum and no harm to radio network. Only one or more parameters like
P
out
might reduce in their value and exceed the specified tolerances. When the temperature returns
to normal operating temperature levels, the module will meet 3GPP specifications again.
2.4. Functional Diagram
The following figure shows the block diagram of EP06.
upgrade, software debugging, GNSS NMEA output and voice over
USB2.0*
Compliant with USB 3.0 specification
The data transfer rate can reach up to 5.0Gbps.
Used for AT command communication, data transmission, GNSS NMEA
output and voice over USB 3.0*
USB Driver: Windows XP, Windows Vista, Windows 7, Windows 8/8.1,
Windows 10, Linux 2.6 or later, Android 4.0/4.2/4.4/5.0/5.1/6.0
Include main antenna, diversity antenna and GNSS antenna
Support LTE/WCDMA Rx-diversity
Gen8C Lite of Qualcomm
Protocol: NMEA 0183
Compliant with 3GPP TS 27.007, 27.005 and Quectel enhanced AT
commands
Size: (51.0±0.1) × (30.0±0.1) × (4.3±0.2 mm)
Weight: approx. 6g
Operation temperature range: -35°C ~ +75°C
1)
Extended temperature range: -40°C ~ +85°C
2)
Storage temperature range: -40°C ~ +90°C
All hardware components are fully compliant with EU RoHS directive
