Quectel EP06 User Manual

16 / 50
Keep all NC and unused pins unconnected.
3.3. Power Supply
The following table shows pin definition of VCC pins and ground pins.
Table 5: Definition of VCC and GND Pins
The typical supply voltage of EP06 is 3.3V. The power supply must be able to provide sufficient current up
to 2A at least, and a bypass capacitor of no less than 470µF with low ESR should be used to prevent the
voltage from dropping.
46
LED_WPAN#
ANTCTL3/
GPIO3
IO
External switch control for
multiple antenna/
General purpose I/O
1.8V power
domain
47
RESERVED
PCM_DOUT
DO
PCM data output
48
1.5V
NC
Not connected
49
RESERVED
PCM_DIN
DI
PCM data input
50
GND
GND
Ground
51
RESERVED
PCM_SYNC
IO
PCM frame synchronization
input in slave mode and output
in master mode
52
3.3Vaux
VCC
PI
3.3V DC supply
Vmin=3.1V
Vnorm=3.3V
Vmax=4.4V
Pin No.
Pin Name
I/O
Power Domain
Description
2, 24, 39,
41, 52
VCC
PI
3.1~4.4V
3.3V DC supply
4, 9, 15,
18, 21, 26,
27, 29, 34,
35, 37, 40,
43, 50
GND
Ground
NOTE
