Quectel GNSS Series User Manual

GNSS Module Series
L26-LB EVB User Guide
L26-LB_EVB_User_Guide 7 / 28
2 General Overview
2.1. Top View
The following figure illustrates the top view of L26-LB EVB.
A
B
C
E
D
F
G
H
I
J
K
Figure 1: Top View of L26-LB EVB
Table 1: Interfaces of L26-LB EVB
SN.
Reference
Number
Description
A
J301
UART Connector
B
S301
USB ←→ UART (USB/UART alternation switch)
C
S102
RESET button
