GNSS Module Series
L26-LB EVB User Guide
L26-LB_EVB_User_Guide 8 / 28
2.2. EVB Kit Accessories
USB Flash
Drive
EVB
GNSS
Antenna
Bolts and
Coupling Nuts
USB
Cable
Figure 2: L26-LB EVB Kit Accessories
D
S103
FORCE_ON button
E
S201
POWER switch
F
J201
Micro USB connector
G
D105, D106
Indication LEDs
H
J101
Antenna connector
I
U103
L26-LB module
J
S101
STANDBY switch
K
J106
Test points
