Fitting guide -
for printed wheel covers
Feed wheel cover (at slot) behind the mudguard stay and over hub.
Align holes in covers either side of the wheel. (3 holes Kitten wheel
covers, 5 holes Colt/Carousel, 5 holes Panther).
Insert longer (female) plastic fastening through holes in each disc
and secure using smaller (male) fastening
Notes on tting wheel discs
Finger tighten, do not over tighten, if using a screwdriver as this
may split the fastenings.
Repeat for each set of holes.
Carefully tuck the exposed edge at the split disc, behind the secured
edge. Black (unprinted) discs are to be used on the inside of the
rear wheels.
You will need to remove the discs as appropriate for access to the
valve for inating tyres (Kitten Trike). The rear Colt and Carousel wheel
covers have cutouts for access on rear wheels. When retrotting wheel
covers to the Colt, Carousel and Panther tricycles, you will need to
remove any reectors from the wheels.
