Chapter 5 Typical Application
5.1 Basic connection
RC832-30
TX RXPWR
LLOS
OUT RLOSIN
RC832-30
ALM/
LPR
TX RXPWR
LLOS
OUT RLOSIN
RC832-30
ALM/
LPR
E1
Device
E1
Device
Client Site
CO Site
As is shown in the figure above, RC832-30 can be applied in pair and network management can be
realized on the application. In addition, RC832-30 can also be inter-connected with
RCMS2802-30FE/60FE-BL, RC832-60, RC832-30/60-BL, RC831-60-FV35, and etc.
RC832-30-BL
E1
Device
E1
Device
Client Site
CO Site
