25.7Adjustingthetonecontrols

TheBass,Middle,andTrebletonecontrolscanbe

adjusted.

FromtheFusionlinkapplication:

1.SelecttheMenuicon.

2.SelectToneControls.

3.SelecteitherBass,Middle,orTreble.

4.Adjusttheleveltotherequiredsetting.

5.SelectBacktogobacktothemenuoptions.

6.SelectBackfromthemenuoptionstogobackto

themainscreen.

25.8Selectingthesystemtocontrol

WheremorethanoneFusionentertainmentsystem

isconnectedyoucanselectwhichsystemtheFusion

linkapplicationwillcontrol.

FromtheFusionlinkapplication:

1.SelecttheMenuicon.

2.SelectSelectFusionsystem.

Alistofavailablesystemsisdisplayed.

3.Selectthesystemyouwanttocontrol.

TheFusionlinkapplicationwillnowcontrolthe

selectedsystem.

Fusionlinkapplication

381
