6 Chapter 1
Graphics contained within this publication are for representation only.
Connections & Setup
The Front of Your TV
Front Input Jacks
The TV has front input jacks for your convenience: one set of audio/video inputs. To
access the component you connected to the front of the TV, press the INPUT button on
your remote until FRNT appears on the screen. The jacks are ideal for connecting a video
game console or a camcorder.
Note: When connecting a component that has only one audio jack, such as some camcorders, use the
TV’s AUDIO L /MONO jack to hear the audio.
VIDEO Receives video from another component such as a VCR, camcorder, or video
game console.
L/MONO and R AUDIO Receives audio from another component such as a VCR,
camcorder, or video game console.
Front Panel Buttons
If you cannot locate your remote, you can use the front panel buttons of your TV to
operate many of the TV’s features.
MENU Brings up the Main menu.
CH v Scans down through the current channel list. In the menu system, acts like the
down arrow button on the remote control and adjusts menu controls.
CH Scans up through the channel list. In the menu system, acts like the up arrow
button on the remote control and adjusts menu controls.
VOL - Decreases the volume. In the menu system, acts like the left arrow button on
the remote control and adjusts menu controls.
VOL + Increases the volume. In the menu system, acts like the right arrow button on
the remote control and adjusts menu controls.
POWER Turns the TV on and off.
v
