4
First-Time Operation
3. Adjust the handstrap to fit your hand.
LENS
Cover
Control
Handstrap
Handstrap Velcro
Strip (Under Flap)
2. Attach the adapter/charger.
VCR
CAMERA
POWER
OFF
DC OUT
Jack
DC Cable
Adapter/
Charger
To AC 100-240,
50/60 Hz
• Connect the other end of the DC
cable to the DC in jack on the
camcorder as shown above.
• Plug the adapter/charger’s plug
into an operating outlet.
Since the battery must be charged
before it can be used the first time,
attach the adapter/charger to the
camcorder.
• Connect one end of the DC cable
to the DC OUT jack on the
adapter/charger.
• Lift the flap on the
handstrap and separate
the velcro strip.
• Insert your hand, adjust
the strap to fit snugly,
refasten the strap, and
close the flap.
4. Slide LENS COVER control to open lens cover.
DC In Jack
To Next Page
