57
Playback
Playback
Use the Viewfinder for Playback
You can see tapes using the viewfinder. There is no sound during
viewfinder playback.
To Play Back a Tape
1. Attach a power supply.
Attach the adapter/charger, charged
battery, or optional car cord.
2. Insert a tape.
• Slide the EJECT switch to open the
cassette compartment.
• Turn the tape wheel on the cassette
to remove any slack from the tape.
• Insert the cassette with the tape
wheel facing up and the tape
window facing out.
• Press on the PUSH button to lock
the cassette compartment closed.
3. Set the POWER switch to VCR.
The power indicator lights.
4. Adjust the viewfinder for a
comfortable viewing position.
• Turn the eyepiece focus control to
adjust the focus of the viewfinder
for your vision.
5. Press the PLAY/PAUSE button to
begin playback.
• If necessary, adjust tracking.
• During playback, use the playback
features on the following pages.
6. Press the STOP button when you
are finished.
REW (Rewind) Button
EJECT
Switch
STOP Button
Viewfinder
Eyepiece Focus Control
PLAY/PAUSE Button
FF (Fast Forward) Button
POWER Switch
in VCR
To Next Page
