Chapter 1: Getting Started
2
Graphics contained within this publication are for representation only. Your unit might differ slightly.
Dipole Antenna Connection
Follow the steps to connect the indoor antenna (supplied with model E13320) with your TV (only if
you do not connect an outdoor antenna or a cable-TV system).
Insert the antenna base into the pocketed slot on the back of your set. Stand at the back of your set with
the antenna twin-lead facing you, and press the base of the antenna into the slot until it locks in place.
Connect the ends of the twin-lead to the Antenna Adapter (supplied with model E13320).
Connect the Antenna Adapter to the ANTENNA connector on the back of the TV.
Later, after you’ve turned on the TV, adjust the length and position of the antenna rods for best
reception.
• For viewing VHF channels, extend the rods fully.
• For viewing UHF channels, shorten the rods for best reception.
