Re S.p.A. TL01-A
03/07/12 10/13
Electrical characteristics
Power supply : 12÷24Vdc.
Analog output : 0÷5Vdc; 0÷10Vdc (optional).
CCD sensor : format 2048 square pixels 0,014 x 0,014 mm
High reading speed : >1000 times per sec. (cycle time=1msec)
Communication with regulator through LIN serial
High reliability. Use of programmed logic (CPLD)
Long illumination time
Protected against polarity inversions and short circuits
Protected against ESD (in compliance with EN61000-4-2)
Complies with EN61000-6-2 (2005) and EN61000-6-3 (2007)
Other characteristics
Viewing area : 28mm
Adjustable reading area : 1-28mm
EMD (Micrometrical Electronic Movement) : 0,1mm
No line/edge indication by switching on a red LED
Sturdy and compact : dimensions 80 x 50 x 60mm (L x P x H)
Response time : 1msec
Working temperature range : 0÷60°C
Degree of protection : IP40
Inversion of the reading direction without recalibrating the system
Focus procedure to be performed only once during the first installation (even if the material being
used changes, you do not have to repeat the procedure, simply perform the calibration)
No mechanical adjustment required for different materials being used (even if transparent or
metallized)
Possibility of selecting the sensor response when there is no line/edge:
1. Storing the last value read: the belt guide searches for the line/edge even if it is outside of the
sensor’s field of view.
2. Signal to the regulator that there is no line/edge: the regulator stops and waits for the
line/edge to reappear inside the sensor’s field of view.
Optional
Remote keyboard
Possibility to increase the degree of protection
Sensor cable with custom length
Analog output 0÷10Vdc
