Red Sea MAX
®
NANO
34
6 Installation der Bauteile im hinteren Filterbereich
1. Abnehmbarer Überlaufkamm
2. Eiweißabschäumer
3. Aktivkohle
4. Strömungspumpe
5. Pumpen-Auslassdüse
6. Schwamm zum Zurückhalten von Luftblasen
7. Schwamm am Abschäumerauslass
8. Automatische Nachfüllanlage
9. Micron Filterbeutel
Montageskizze der rückseitigen Filterbereich-Bauteile für das MAX
®
NANO.
9
7
2
5
6
3
1
8
4
