1.14
FRONT ARMREST/HEATED SEATS
The central armrest 1 has several
different adjustment positions
(from A to D).
Raised position A
This should be used to:
• access the seat adjustment
controls.
• fasten your seat belt
(access to the casing 3).
Adjusting the armrest
To lower, unlock the armrest by
pressing handle 2 and adjust to the
desired position.
To raise the armrest, simply lift it
up.
Heated seats
With the ignition on, press
switch 4. An indicator light will
light up on the instrument panel.
Even if the indicator light is lit
up, the system is not necessarily
activated. The system has a
thermostat and only operates
when the passenger compartment
temperature is less than 12°C (with
a tolerance of plus or minus 4°C).
