3.3 Basic Setup for the RH850/F1KM-S1 Starter Kit
The board is mainly designed to operate with the RH850/F1KM-S1 Starter Kit. To
setup the connection to the Starter Kit board please use the 9-Pin Sub-D
connector to establish the interconnection.
When you use the demo software for the SENT application board together with
the RH850/F1KM-S1 Starter Kit V3, please be sure that the SENT software
example is loaded onto the RH850 MCU device on the Starter Kit.
Figure 2: Interconnection with the Y-ASK-RH850F1KM-S1-V3
Table 5: Initial Jumper and Switch Settings on Starter Kit
Switch S5
Jumper J19
