TM031 Integrity 18, 20, 24, 26L Service Instructions REV: B
D.O.I: February 2008
This document is stored and maintained electronically by Service. All printed copies not bearing this statement in RED are deemed “uncontrolled”
Exploded View Replacement Parts List 5 - 871024-C, 871026 & 871026B Models
Fitted with solenoid operated bypass
Front Panel Rheem Brand (50 & 60ºC Models)
Proportional Gas Flow Regulating Valve
Lower Burner Assembly – NG
Lower Burner Assembly – LP
Flame rod assembly (3 x flame rods)
Burner Change-Over Assembly
Water Inlet Connector Assembly 26 L (¾)
Water Drain Valve Assy (includes water filter)
Water Body Assy including solenoid bypass
Heat Exchanger and Combustion Chamber
Combustion Chamber Front Panel Assembly
Hot water Outlet Connector (¾)
Over Heat Limiter Assembly
Truss Gasket Screw 4 x 10
Nozzle Plate Bind Screw 3 x 6
*When installed in 871024-C, 871026 & 871026-B model heaters these parts will require the
replacement of other interconnecting components. Refer to „Product Changes‟ on page 10 and
„Parts Replacement Scenarios‟ on page 11 for more information.
Note: For controller and controller cable part numbers refer to page 20.
