SPECIFICATIONS
RECOVERY CAPACITIES
Recovery in U.S. Gallons/Hr. (GPH) and Liters/Hr. (LPH) at Various Temperature Rises
MODEL
NUMBER
INPUT (BTU/HR)
NAT. & LP
THERMAL
EFFICIENCY
UNITS
40°F
(22.2°C)
50°F
(27.8°C)
60°F
(33.3°C)
70°F
(38.9°C)
80°F
(44.4°C)
90°F
(50.0°C)
100°F
(55.6°C)
110°F
(61.1°C)
120°F
(66.7°C)
HE55-100 100,000 95%
GPH 288 230 192 165 144 128 115 105 96
LPH 1090 872 726 623 545 484 436 396
363
HE55-130
HE80-130
HE119-130
130,000 95%
GPH 374 299 249 214 187 166 150 136 125
LPH 1417
1
133 944 809 708 630 567 515 472
HE80-160
HE119-160
160,000 95%
GPH
461 368 307 263 230 205 184 167 154
LPH 1744
1395 1
162 996 872 775 697 634 581
HE80-199
HE119-199
199,000 95%
GPH 573 458 382
327 286 255 229 208 191
LPH 2169
1735 1446 1239 1084 964 867 789 723
Recovery rating is based on thermal efficiencies obtained in Intertek testing laboratory.
BOOSTER MODELS
Recovery in U.S. Gallons/Hr. (GPH) and Liters/Hr. (LPH)
MODEL
NUMBER
INPUT (BTU/HR)
NAT. & LP
THERMAL
EFFICIENCY
UNITS
40°F
(22.2°C)
50°F
(27.8°C)
60°F
(33.3°C)
70°F
(38.9°C)
80°F
(44.4°C)
90°F
(50.0°C)
100°F
(55.6°C)
110°F
(61.1°C)
120°F
(66.7°C)
130°F
(72.2°C)
140°F
(77.8°C)
HE55-160 160,000 95%
GPH 461 368 307 263 230 205 184 167 154 142 132
LPH 1744 1395 1
162 996 872 775 697 634 581 536 498
HE55-199 199,000 95%
GPH 573
458 382 327 286 255 229 208 191 176 164
LPH 2169 1735 1446 1239 1084 964 867 789 723 667 620
All models exceed the minimum energy efficiency requirements of current ASHRAE 90.1 requirements.
MAXIMUM DELIVERY
In U.S. Gallons and Liters (Includes useable storage and recovery for indicated times)
MODEL
NUMBER
GALLONS/
LITERS
MAX
SETPOINT
INPUT (BTU/HR)
NAT. & LP
TEMP.
RISE UNITS
5
MIN.
10
MIN.
15
MIN.
20
MIN.
30
MIN.
45
MIN.
1
HR.
2
HR.
3
HR.
MIN. TO RECOVER
CONTENTS
HE55-100
55
208
160º
71ºC
100,000
100°F GAL. 48 58 67 77 96 125 154 269 388
29
37.7°C LTR. 182 219 255 291 364 473 582 1019 1455
HE55-130
55
208
160º
71ºC
130,000
100°F GAL. 51 63 76 88 1
13 151 188 338 488
22
37.7°C
LTR. 193 240 288 335 430 571 713 1281 1848
HE80-130
80
303
160º
71ºC
130,000
100°F
GAL. 68 81 93 106 131 168 206 355 505
32
33.7°C
LTR. 259 306 354 401 495 637 779 1345 1912
HE119-130
119
450
160º
71ºC
130,000
100°F GAL. 96 108 121 133 158 196 233 383
532
48
33.7°C LTR. 363 410 457 504 599 750 882 1449 2015
HE55-160
55
208
180º*
82ºC
160,000
100°F GAL. 54 69 85 100 131 177 223 407 591
18
37.7°C
L
TR. 204 262 320 379 495 670 844 1542 2241
HE80-160
80
303
160º
71ºC
160,000
100°F
GAL.
71
87
102
1
17
148
194
240
424
609
26
37.7°C L
TR. 270 328 386 444 561 735 909 1607 2304
HE1
19-160
119
450
160º
71ºC
160,000
100°F GAL. 99 114 129 145 175 221 268
452 636
39
37.7°C L
TR. 373 432 490 548 664 838 1013 1710 2408
HE55-199
55
208
180º*
82ºC
199,000
100°F
GAL. 57 77 96 115 153 210 268 497
726
14
37.7°C L
TR. 218 291 363 435 580 797 1014 1883 2751
HE80-199
80
303
160º
71ºC
199,000
100°F
GAL. 75 94 113 132 171 228 285 514
743
21
37.7°C L
TR. 284 357 429 501 646 863 1079 1947 2814
HE1
19-199
119
450
160º
71ºC
199,000
100°F GAL. 102 121 141 160 198 255 312 542
771
31
37.7°C L
TR. 338 460 532 604 749 966 1183 2050 2918
All models have a maximum setpoint of 160°F with the exception of the HE55-160 and HE55-199 booster models. The HE55-160 and HE55-199 have a maximum setpoint of 180°F.
* NOTE: The 180º F models are shipped with all necessary components for an approved installation (see Booster Installation Kit for component list on Page 7.)
DIMENSIONAL INFORMATION
All dimensions shown in English and Metric
MODEL WATER CONNECTIONS APPROX
NUMBER UNITS HEIGHT WIDTH DEPTH VENT
INLET OUTLET
SHIPPING WT.
HE55-100
HE55-130
inches 52 23 1/2 32
2 1 1 175 lbs.
mm 1321 597 813 51 25 25 79 kgs
HE55-160
HE55-199
inches 52
23 1/2 32 3 1 1 175 lbs.
mm 1321 597 813 76 25 25 79 kgs
HE80-130
HE80-160
HE80-199
inches 72 23 1/2 32 3* 1-1/2 1-1/2 235 lbs.
mm 1854 597 813 76 38 38 106 kgs
HE1
19-130
HE119-160
HE119-199
inches 73 27 36 3* 1-1/2 1-1/2 405 lbs.
mm 1854
686 914 76 38 38 184 kgs
All models require a 120V power source.
* 130,000 Btu models are certified to be installed with 2" venting.
0" CLEARANCE TO
COMBUSTIBLES ON ALL
ADVANTAGEPLUS
UNITS, HOWEVER, A 24"
(61 cm) CONTROL PANEL
SERVICE CLEARANCE IS
RECOMMENDED.
