Model Features/Physical Data & Specifications
R801S (UF/HZ) Series
4
MODEL NUMBERS R801S SERIES R801SA050314M*A R801SA075417M*A R801SA100521M*A R801SA125524M*A R801SA150524M*A
Input-BTU/Hr [kW] ➁
50,000 [15] 75,000 [22] 100,000 [29] 125,000 [37] 150,000 [44]
Heating Capacity BTU/Hr [kW] ➀
40,000 [12] 60,000 [18] 80,000 [23] 100,000 [29] 120,000 [32]
Heat Ext. Static Pressure [kPa] .10 [.025] .12 [.029] .15 [.037] .20 [.05] .20 [.05]
Blower (D x W) [mm]
11 x 6
[279 x 152]
11 x 7
[279 x 178]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
Motor H.P.–Speed–
PSC Type [W]
1
/3-4-PSC
[248]
1
/2-4-PSC
[373]
1
/2-4-PSC
[373]
3
/4-4-PSC
[560]
3
/4-4-PSC
[560]
Motor Full Load Amps 5.7 7.8 7.5 8.4 9.3
Heating Speed Med-Low Med-High Med-Low Med-High Med-High
Cooling Speed High High High High High
Cooling CFM @ Rating Point
[L/s]
1250
[590]
1650
[780]
1800
[850]
1750
[825]
1900
[900]
Max. E.S.P. (In. W.C.) [kPa] 0.8 [.20] 0.8 [.20] 0.8 [.20] 0.8 [.20] 0.8 [.20]
Temperature Rise Range °F
[°C]
25-55
[13.9-30.6]
25-55
[13.9-30.6]
35-65
[19.4-36.1]
35-65
[19.4-36.1]
45-75
[25-41.7]
Max. Outlet Air Temp. °F
[°C]
155
[68.3]
155
[68.3]
180
[82.2]
165
[73.8]
190
[87.7]
Approx. Shipping Weight (Lbs.)
[kg]
110
[50]
125
[57]
140
[64]
150
[68]
160
[73]
AFUE ➀
80.0% 80.0% 80.0% 80.0% 80.0%
NOTES: All models are 115V, 60HZ, 1 Ph. Gas connection size for all models is
1
/2" [12 mm] N.P.T.
➀ In accordance with D.O.E. test procedures.
➁ See Conversion Kit Index Form for high altitude derate.
* S = Standard, X = Low Nox
[ ] Designates Metric Conversions
• 80% residential Gas Furnace CSA certified
•
3 way multi poise design UF / HZ
•
PlusOne
™
Diagnostics — 7 Segment LED all units
•
PlusOne
™
Ignition System – DSI for reliability and longevity
•
Heat exchanger is removable for improved serviceability.
Aluminized steel construction provides maximum corrosion
resistance and thermal fatigue reliability.
•
Solid doors provide quiet operation
•
Low profile 34" cabinet ideal for space constrained
installations
•
Blower shelf design serviceable in all furnace orientations
•
Hemmed edges on cabinets and doors
•
1/4 turn door knobs for tool less access
•
Integrated Controls board features dip switches for easy
system set up
• QR codes for quick access to product information from your
smart phone or tablet
Model Features
Physical Data and Specifications
