Rheem P16 Series User Manual

6
“L”
“W”
“H”
A
I
R
D
I
S
C
H
A
R
G
E
ALLOW 60” [1524mm]
OF CLEARANCE
AIR INLET LOUVERS ALLOW
6” [152mm] Min. OF CLEARANCE ALL SIDES
12” [305mm] RECCOMMENDED
SERVICE PANELS/
INLET CONNECTIONS / HIGH & LOW
VOLTAGE ACCESS
ALLOW 24” [ 610 mm] OF CLEARANCE
ST-A1226-02-00
ALLOW 60" [1524mm] OF
CLEARANCE
SERVICE PANELS/
INLET CONNECTIONS /
HIGH & LOW VOLTAGE
ACCESS ALLOW
24" [610 mm] OF
CLEARANCE
AIR INLET LOUVERS ALLOW
6" [152 mm] OF CLEARANCE ALL SIDES
12" [305 mm] RECOMMENDED
(-) P 16 24 A J 2 N A
MINOR SERIES
Z
TYPE
2 - TWO STAGE
VOLTAGE
J = 1 PH, 208-230/60
A = NATIONAL HEAT PUMP 1ST DESIGN
B = NATIONAL HEAT PUMP 2ND DESIGN
F = DUAL FUEL HEAT PUMP
CAPACITY
24 = 24000 BTU/HR [7.03 kW]
36 = 36000 BTU/HR [10.55 kW]
48 = 48000 BTU/HR [14.07 kW]
60 = 60000 BTU/HR [17.58 kW]
16 SEER
HEAT PUMP
BRAND
CONTROLS
C - COMMUNICATING
N - NON-COMMUNICATING
GENERAL INFORMATION
General Information
NOTE: Actual unit
appearance may vary.

Rheem P16 Series Specifications

General

Brand	Rheem
Model	P16 Series
Category	Heat Pump
Language	English
