FIGURE 33
ON A REPLACEMENT FURNACE CONTROL THE ORIGINAL MEMORY CARD FROM THE ORIGINAL FURNACE CONTROL SHOULD BE INSERTED
INTO CONNECTOR J11 OF THE REPLACEMENT CONTROL. DOING THIS WILL GIVE THE REPLACEMENT CONTROL ITS IDENTITY. NOTE THAT
THERE WILL BE TWO MEMORY CARDS – THE ORIGINAL (INSERTED INTO J11) AND THE REPLACEMENT (STILL ATTACHED TO THE REPLACE-
MENT FURNACE CONTROL).
TETHER SECURING ORIGINAL
MEMORY CARD TO FURNACE – DO
NOT CUT THIS TETHER OR
REMOVE THE ORIGINAL
MEMORY CARD FROM THE
FURNACE WHEN REPLACING
THE FURNACE CONTROL (I.F.C.)
43
