Rheem RGPS series User Manual

Air
Model Features/Physical Data & Specifications
RGPS Series
4
Physical Data and Specifications
MODEL NUMBERS
RGPS- SERIES
05EAUER
05NAUER
07EAMER
07NAMER
07EAMGR
07NAMGR
10EAMER 10EBRGR
10EBRJR
10NBRJR
12EARJR 15EARJR
Input-BTU/Hr [kW] ➁
50,000 [15] 75,000 [22] 75,000 [22] 100,000 [29] 100,000 [29] 100,000 [29] 125,000 [37] 150,000 [44]
Heating Capacity BTU/Hr [kW] ➀
41,000 [12] 60,000 [18] 60,000 [18] 80,000 [23] 80,000 [23] 80,000 [23] 99,000 [29] 119,000 [35]
Heat Ext. Static Pressure [kPa] .10 [.025] .12 [.029] .12 [.029] .15 [.037] .15 [.037] .15 [.037] .20 [.05] .20 [.05]
Blower (D x W) [mm]
11 x 6
[279 x 152]
11 x 7
[279 x 178]
11 x 7
[279 x 178]
11 x 7
[279 x 178]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
Motor H.P.–Speed–
PSC Type [W]
1
/2-4-PSC
[373]
1
/2-3-PSC
[373]
1
/2-3-PSC
[373]
1
/2-3-PSC
[373]
1
/2-3-PSC
[373]
3
/4-3-PSC
[560]
3
/4-3-PSC
[560]
3
/4-3-PSC
[560]
Motor Full Load Amps 6.8 5.8 7.9 7.1 7.9 9.5 9.5 9.5
Heating Speed Med-Low Med Med Med Med Low Low Low
Cooling Speed High High High High High Med Med Med
Cooling CFM @ .5" E.S.P.
(Nominal) [L/s]
1200
[566]
1200
[566]
1600
[755]
1200
[566]
1845
[871]
2060
[922]
2115
[998]
2080
[982]
Max. E.S.P. (In. W.C.) [kPa] 0.5 [.12] 0.5 [.12] 0.5 [.12] 0.5 [.12] 0.5 [.12] 0.5 [.12] 0.5 [.12] 0.5 [.12]
Temperature Rise Range °F
[°C]
25-55
[13.9-30.6]
35-65
[19.4-36.1]
25-55
[13.9-30.6]
45-75
[250-41.7]
30-60
[16.7-33.3]
30-60
[16.7-33.3]
35-65
[19.4-36.1]
50-80
[27.8-44.4]
Max. Outlet Air Temp. °F
[°C]
155
[68.3]
165
[73.8]
155
[68.3]
190
[87.7]
170
[76.6]
170
[76.6]
180
[82.2]
190
[87.7]
Standard Filter (In.)
[mm]
15
3
/4 x 25
[400 x 635]
15
3
/4 x 25
[400 x 635]
15
3
/4 x 25
[400 x 635]
15
3
/4 x 25
[400 x 635]
19
1
/4 x 25
[489 x 635]
19
1
/4 x 25
[489 x 635]
22
3
/4 x 25
[578 x 635]
22
3
/4 x 25
[578 x 635]
Return Air Cabinets
(Opt.) RXGR-
Filter Size [mm]
C14B
(2) 12 x 16
[305 x 406]
C17B
(2) 12 x 16
[305 x 406]
C17B
(2) 12 x 16
[305 x 406]
C17B
(2) 12 x 16
[305 x 406]
C21B
(2) 20 x 16
[508 x 406]
C21B
(2) 20 x 16
[508 x 406]
C24B
(2) 24 x 16
[610 x 406]
C24B
(2) 24 x 16
[610 x 406]
AFUE–H.S.I. Models ➀
80.0% 80.0% 80.0% 80.0% 80.0% 80.0% 80.0% 80.0%
Approx. Shipping Weight (Lbs.)
[kg]
85
[39]
105
[48]
105
[48]
115
[52]
120
[54]
120
[54]
140
[63]
150
[68]
NOTES: All models are 115V, 60HZ, 1 Ph. Gas connection size for all models is
1
/2" [12 mm] N.P.T.
➀ In accordance with D.O.E. test procedures.
➁ See Conversion Kit Index Form for high altitude derate.
[ ] Designates Metric Conversions
• The design is certified by CSA International.
• Unique solid door design leads to quiet operation.
• Patented heat exchanger, constructed of aluminized steel for the
maximum in corrosion resistance and thermal fatigue reliability.
• Low profile “34 inch” [864 mm] design is lighter and easier to
handle, and leaves room for optional equipment.
• Convertible from upflow to horizontal left or right without field
conversion.
• Left or right side gas and electric inlet connections allow
quick and simple change.
• Direct spark ignition with remote sense, features a integrated
board with an electronic air cleaner hookup.
• Prepaint galvanized steel cabinet.
• A slow-open gas valve and a specially designed draft inducer
motor make it one of the quietest furnaces on the market
today.
• Grab-holes in doors to aid in easy door removal and
replacement.
Model Features

Rheem RGPS series Specifications

General

Brand	Rheem
Model	RGPS series
Category	Furnace
Language	English
