Rheem RGPS series User Manual

Air
Accessories
RGPS Series
9
RETURN AIR CABINETS
A
IN. [mm]
FILTER SIZE
IN. [mm]
RXGR-C14B 14
1
/4 [356] (2) 12 x 16 [305 x 406]
RXGR-C17B 17
1
/2 [445] (2) 12 x 16 [305 x 406]
RXGR-C21B
21
1
/4 [533]
(2) 20 x 16 [508 x 406]
RXGR-C24B 24
1
/2 [622] (2) 24 x 16 [610 x 406]
FILTER RACK FILTER SIZES† INCHES [mm]
10EBRGR & 10EBRJR
MODEL
RGPS-
RXGF-CA
(SIDE)
05, 07, 10EA
15
3
/4 x 25
[400 x 635]
15
3
/4 x 25
[400 x 635]
12, 15
15
3
/4 x 25
[400 x 635]
†Filter racks are shipped without filters.
A 1" [25.4 mm] filter may be used.
*Designates “E” or “N”.
THE RXGR-C24B MUST ONLY BE INSTALLED ON THE SIDE
OPPOSITE THE GAS AND ELECTRICAL CONNECTIONS.
WARNING: IMPORTANT NOTICE
A SOLID METAL BASE PLATE (SEE TABLE) MUST BE IN PLACE WHEN THE FURNACE IS
INSTALLED WITH SIDE AIR RETURN DUCTS. FAILURE TO INSTALL A BASE PLATE COULD
CAUSE PRODUCTS OF COMBUSTION TO BE CIRCULATED INTO THE LIVING SPACE AND
CREATE POTENTIALLY HAZARDOUS CONDITIONS.
FURNACE BASE
WIDTH
SOLID BOTTOM BASE
PLATE SIZE
IN. [mm]
KIT NO. PLATE NO.
IN. [mm]
14
1
/2 [356] RXGB-D14 AE-61874-01 11
5
/8 x 23
9
/16 [295 x 598]
17
1
/2 [445] RXGB-D17 AE-61874-02 15
1
/8 x 23
9
/16 [384 x 598]
21
1
/2 [533] RXGB-D21 AE-61874-03 18
5
/8 x 23
9
/16 [473 x 598]
24
1
/2 [622] RXGB-D24 AE-61874-04 25
5
/8 x 23
9
/16 [651 x 598]
FOR HIGH ALTITUDES:
OPTION CODE FOR HIGH ALTITUDE: U.S. & Canada
None required for high altitudes.
HIGH ALTITUDE CONVERSION KITS: U.S. & Canada
None required for high altitudes.
80+ HIGH ALTITUDE INSTRUCTIONS
CAUTION: Always follow National Fuel Gas Code (NFGC) guidelines
when converting for high altitudes.
High altitude option codes are not required for these models.
However, the burner orifice size needs to be recalculated and verified
at elevations above 2000 ft. See Installation Instructions for more
information.
NOTE: For Canadian installations only, an optional derate (manifold
gas pressure reduction) method may be used to adjust the
furnace for altitude. See Installation Instructions for more
information. This optional method may NOT be used for U.S.
installations.
[ ] Designates Metric Conversions
INTERNAL FILTER RACK FOR BOTTOM
OR SIDE RETURN: RXGF-DA*
Each order contains (1) one box of 10 filter racks supplied without
filters.
*Filters available through PROSTOCK
®
.
SIDE RETURN FILTER RACK: RXGF-CA
BOTTOM RETURN FILTER RACK FOR
UPFLOW APPLICATION: RXGF-CB
ACCESSORY RETURN
AIR CABINETS
Return Air Cabinets may
be installed on either side
application except RXGR-C24B
(side application must be
on side opposite gas and
electrical connections).
RXPF-F01 and F02
FOSSIL FUEL KIT—is for use with Rheem Value Series Heat Pumps
and air furnaces. RXPF-F02 meets TVA requirements.
RXGP-F03
TWINNING KIT—is for parallel operation requirements.
