DANGER:
Failure to properly vent the water heater to the outdoors
as outlined in this Venting section will result in death or
serious personal injury. To avoid the risk of fire, explosion,
or asphyxiation from carbon monoxide, NEVER operate the
water heater unless it is properly vented and has adequate
air supply for proper operation as outlined in this Venting
section. This water heater must have air supply connected
and terminated to the outdoors.
WARNING:
Refer to page 16 for required clearances to combustible
materials. Improper clearances can cause explosion or fire
resulting in death, personal injury, and/or product damage.
CAUTIONS:
•
Check to make sure flue gases DO NOT recirculate into the
air intake terminal when using direct venting. If the water
heater is having service issues, flue recirculation may be a
contributing factor.
• Even when the minimum vent terminal separation
distances are followed, recirculation may still occur
depending upon the location outside the building, the
distance from other buildings, proximity to corners,
weather conditions, wind patterns, and snow depth.
• Periodically check to make sure that flue recirculation
is not occurring. Signs of flue gas recirculation include
frosted or frozen intake terminals and condensate in the
intake terminal and venting system.
• Correction to flue recirculation may involve angling the
intake away from the exhaust terminal and increasing the
distance between them. Check to be sure the intake and
exhaust terminals are not obstructed, especially during
periods of below-freezing weather.
Venting Requirements
The installation of venting must comply with national
codes, local codes, and the vent manufacturer’s
instructions.
The vent exhaust and air intake must terminate
outside as described in these instructions. DO NOT
vent this water heater through a chimney. It must be
vented separately from all other appliances.
NOTICE:
The unit can be vented using only the following approved
vent pipe material.
Use only 2 or 3 inch diameter pipe. Refer to local
codes for restrictions on the use of InnoFlue® PP,
PVC, CPVC, or ABS pipe and fittings. All exhaust
venting materials for product installed in Canada
must meet ULC-S636.
The use of cellular core PVC (ASTM F891), cellular
core CPVC, or Radel® (polyphenolsulfone) in non-
metallic venting systems is prohibited and that
covering non-metallic vent pipe and fittings with
thermal insulation is prohibited.
This water heater requires a special venting
system. Refer to venting supplier’s instruction for
complete parts list and method of installation.
The manufacturers and product lines listed on the
following tables have been tested and authorized to
safely operate with Rheem tankless water heater.
Approved Vent Materials, Fittings and Terminations:
ABS is not permitted for exhaust vent in Canada
Approved Polypropylene Vent Manufacturer/Trade Name:
*Refers to variations in nominal size.
DO NOT USE Schedule 20, Cell Core, Drain Pipe,
Galvanized, Aluminum, B-Vent, or any flexible vent.
20
INSTALLATION INSTRUCTIONS
Venting for Direct-Vent Water Heater
Venting
Acceptable Materials
for Exhaust
Acceptable Materials
for Air Intake
Fittings
Terminations
(Manufactured
by Polytech)
Schedule 40,
ASTM D-1785
Schedule 40,
ASTM D-1785,
and DWV,
ASTM-D2665
Schedule 40,
ASTM D-2665
SP20285
SP20286
SP20245
SP20897
PVC
Schedule 40,
ASTM F-441
Schedule 40,
ASTM F-441,
and CPVC 4120,
ASTM-D2846
Schedule 40,
ASTM F-438
SP21025
SP21026
CPVC
Schedule 40,
ASTM D-2661
Schedule 40,
ASTM D-2661
Schedule 40,
ASTM D-2661
ABS
Manufacturer
Trade Name
Single Wall Pipe
Elbow
Adapter
Non-Return Valve (NRV)
Siphon
Termination
Centrotherm
InnoFlue®
ISVL**** or ISVL****UV
ISELL**** or ISELL****UV
ISAAL0202
ISNRV****
IASJBVS
ISLPT**** or ISTT****
