Rheem RWI Series User Manual

4
GENERAL INFORMATION
FIGURE 1
THE RWI(-) SERIES HYDRONIC AIR HANDLERS ARE DESIGN-CERTIFIED BY UL
1. DOOR SWITCH
2. JUNCTION BOX
3. TRANSFORMERS
4. CAPACITORS
5. LOW VOLTAGE (THERMOSTAT) TERMINAL
6. BLOWER
7. PUMP (IF REQUIRED)
8. WATER INLET (OUTLET FOR 14” HAH)
9. WATER OUTLET (INLET FOR 14” HAH)
10. BLOWER MOTOR
11. HYDRONIC COIL ASSEMBLY
S
11
8
9
10
6
4
7
5
1
2
3
ST-A1242-01-X1

Rheem RWI Series Specifications

General

Brand	Rheem
Model	RWI Series
Category	Air Handlers
Language	English
