Ricoh CX3 User Manual

66
5
Shooting Menu
5 Shooting Menu
The shooting menu is used to adjust camera settings when taking
pictures. To display the shooting menu, press the MENU button when
the camera is in shooting mode.
Using the Menu
1
Press the MENU button in
shooting mode.
• The shooting menu is displayed.
• In scene mode or continuous
mode, press the ADJ./OK button
N to select [MODE] tab, and then
press the ADJ./OK button ". The
shooting menu appears.
Indicates the range of displayed
screens.
2
Press the ADJ./OK button !" to
select the desired menu item.
• If the DISP. button is pressed at
this point, the cursor moves to the
shooting menu tab.
• Press the ADJ./OK button " at the
bottom item to display the next
screen.
3
Press the ADJ./OK button F.
• The menu item settings are displayed.
4
Press the ADJ./OK button !" to
select the setting.
5
Press the ADJ./OK button.
• The setting is confirmed, the shooting menu disappears and the
camera is ready to shoot.
• To select the highlighted option and return to the menu shown in
Step 2, press the ADJ./OK button N.

Ricoh CX3 Specifications

General

Megapixel	10 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.3 \
Maximum image resolution	3648 x 2736 pixels
Optical zoom	10.7 x
Focal length range	4.9 - 52.5 mm
Interface	USB 2.0
Digital SLR	No
Camera shutter speed	1/30 - 1/2000 s
Focal length (35mm film equivalent)	28 - 300 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Spot Auto Focus
Auto Mode focusing range (tele)	1.5 - ∞ m
Auto Mode focusing range (wide)	0.3 - ∞ m
Light metering	centre-weighted, spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200
Light exposure modes	Manual
Flash modes	Auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.28 - 4 m
Flash range (wide)	0.20 - 4 m
Internal memory	88 MB
Compatible memory cards	SD, SDHC
Maximum memory card size	32 GB
Motion JPEG frame rate	5 fps
Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	920000 pixels
Scene modes	Close-up (macro), Documents, Night, Night landscape, Portrait, Sports, Landscape (scenery)
Photo effects	Black&White
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual
Self-timer delay	2 s
Product color	Violet
Battery type	DB-100
Battery life (CIPA standard)	310 shots
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	29.4 mm
Width	101.5 mm
Height	58.3 mm
Weight	185 g
