Ricoh D7510 User Manual

3
2
Y310IA0485
1
4
32
1. Additional display
2. DisplayPort cable
3. RS-232C cable
4. The first display (this machine)
• The RS-232C cable and DisplayPort cable are not supplied and should be purchased separately.
• This RS-232C daisy chain application requires an RS-232C port equipped computer.
• Use RS-232C serial cross cables for daisy chain application.
• The video signals input to the DisplayPort Input jack of the additional display are output from the
DisplayPort Output jack of the first display.
2. Connection
16
