Transport Sensor, Paper Fed Sensor, Paper
End Sensor, Limit Sensor
1. Paper feed unit ( page 12)
2. Transport sensor unit [A] ( ×1, ×1)
3. Transport sensor [A]
1. Replacement and Adjustment
26
