Ricoh MP 9003 User Manual

Direction of paper
grain
Tray 1 Trays 2 and 3 Bypass tray
*1
*1
You can load paper in the orientation into tray 1 only if the A3/11 × 17 tray unit is installed.
• To feed sheets that are smaller than A4 sideways ( ), keep the height of the stacked sheets less
than 20 mm.
The upper edge of the square hole in the side fence on the far side indicates the upper limit.
DPZ042
• When copying or printing is performed onto thick paper on Type1/2, the copy/print speed is
slower than usual.
• Select [Thick Paper 1], [Thick Paper 2], [Thick Paper 3], or [Thick Paper 4] as the paper thickness in
[Tray Paper Settings].
• Even if thick paper is loaded as described above, normal operations and print quality might still not
be possible, depending on the paper type.
• Prints might have prominent vertical creases.
• Prints might be noticeably curled. Flatten out prints if they are creased or curled.
Recommended Paper
145

Ricoh MP 9003 Specifications

General

Print Resolution	1200 x 1200 dpi
Functions	Print, Copy, Scan, Fax
Maximum Paper Size	13" x 19.2"
Duplex Printing	Yes
Automatic Document Feeder	Yes
ADF Capacity	220 sheets
Copy Resolution	600 x 600 dpi
Print Speed	90 ppm
Connectivity	USB, Ethernet, Wi-Fi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps (optional)
Paper Capacity	8, 300 sheets maximum
