Check that the interface board is firmly connected to the controller board.
5. Tighten the two screws to secure the interface board.
6. Connect the USB device server to the machine.
For details, see the Setup Guide provided with the USB device server.
Connecting to the Extra Ethernet Interface with the USB Device Server Option
This section describes how to connect an Ethernet interface cable to the Ethernet port of the optional USB
Device Server.
USB Device Server Option is an interface board for adding an extra Ethernet port. If you install USB
Device Server Option, you can connect two Ethernet cables simultaneously: one to the machine's
Ethernet port and one to the Ethernet port of USB Device Server Option. An IP address can be assigned
to each connection, and you can use one machine to print from different network segments.
Remove the cover of USB2.0 port on the machine and connect the port to the USB port of the USB
device server.
• A network interface cable with a ferrite core must be used for RF interference suppression.
• Use the following Ethernet cables.
• When using 100BASE-TX/10BASE-T:
Unshielded Twisted Pair Cable (UTP) or Shielded Twisted Pair Cable (STP) and Category type
5 or more
• When using 1000BASE-T:
Unshielded Twisted Pair Cable (UTP) or Shielded Twisted Pair Cable (STP) and Category type
5e or more
1. Make sure the main power switch is turned off.
1. Getting Started
38

Ricoh P 502 Specifications

General

Color	No
Duplex printing	-
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF, PostScript 3
Cables included	AC
Cartridge(s) included	Yes
Included cartridge capacity (black)	17400 pages
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1260 W
Power consumption (printing)	- W
Energy Star Typical Electricity Consumption (TEC)	0.49 kWh/week
Paper tray media types	Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	52 - 220 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5, B6
Maximum ISO A-series paper size	A4
Paper input type	Paper tray
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	2100 sheets
Maximum number of input trays	4
Mac operating systems supported	Mac OS X 10.10 Yosemite
Other operating systems supported	IBM AS/400
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Display	LCD
Product color	White
Display diagonal	5 \
Market positioning	Home & office
Storage media	HDD
Internal memory	2000 MB
Processor frequency	1300 MHz
Maximum internal memory	- MB
Internal storage capacity	320 GB
Sound pressure level (printing)	- dB

Weight and Dimensions

Depth	412 mm
Width	375 mm
Height	311 mm
Weight	19300 g
