When the [ ] [ ] [ ] [ ] keys appear in this manual, press the applicable key for the direction that you want
to move the cursor.
4. [OK] key
Use this key to confirm settings or setting values, or move to the next menu level.
5. [Escape] key
Press this key to cancel an operation or return to the previous display.
6. Main Power indicator
Lights up when the machine is ready to receive data from a computer. Flashes when the machine is warming
up or receiving data. It is unlit when the power is off or when the machine is in energy saver mode.
7. Alert indicator
Lights up or flashes when a machine error occurs.
Steady red: paper is jammed, consumables need to be replaced, or a malfunction has occurred.
Flashing yellow: consumables need to be replaced soon, printing is not possible, or printing is possible but
high print quality cannot be achieved.
Follow the instructions that appear on the display.
8. Data in indicator
Flashes when the machine is receiving data from a computer. The data in indicator is lit if there is data to be
printed.
9. [Suspend/Resume] key
Press this to suspend the print job currently being processed. The indicator remains lit as long as the job is
suspended.
To resume the job, press this key again. The suspended job will resume automatically when the time specified
in [Auto Reset Timer] elapses (default: 60 seconds).
For details about the [Auto Reset Timer] setting, see "Timer Settings", Settings.
10. [Job Reset] key
Press to cancel the current print job.
11. [Menu] key
Press this key to configure and check the current machine settings.
Press to change the default settings to meet your requirements.
12. [Switch Functions] key
Press this key to switch between the operation screen of the printer function and the function screens of the
extended features currently in use.
1. Getting Started
46
