Rigol DS6062-DEMO Performance Verification Guide

RIGOL Chapter 2 Performance Verification Test
2-22 DS6000 Performance Verification Guide
Test Record Form
Channel
Fast Edge Signal
Amplitude
Vertical
Scale
Test Result Limit Pass/Fail
CH1
1.2 Vpp 200 mV/div
≤ 0.5 div ×
Minimum Time
Base Scale
[1]
3 Vpp 500 mV/div
CH2
1.2 Vpp 200 mV/div
3 Vpp 500 mV/div
CH3
1.2 Vpp 200 mV/div
3 Vpp 500 mV/div
CH4
1.2 Vpp 200 mV/div
3 Vpp 500 mV/div
Note
[1]
: For different models of oscilloscopes, the minimum time base scales are different. For DS610X, the minimum
time base scale is 500 ps/div; for DS606X, the minimum time base scale is 1 ns/div.
